Engineered for Industrial Automation & Control Cabinets
Standard commercial-grade panels regularly malfunction on factory floors due to airborne dust, electrical noise (EMC), continuous machine vibration, and 24/7 operating stress. The Rostar Tech 15.6” Industrial Touch Panel PC combines a rugged aluminum front bezel with high-performance embedded computing. Designed with an IP65 waterproof/dustproof front panel and seamless panel-mount housing, it ensures 24/7 non-stop operational reliability across manufacturing lines, CNC machinery, smart logistics, and industrial control cabinets.
Key Engineering Highlights
IP65 Front Panel Protection
Robust aluminum front bezel sealed against industrial dust, oil mist, and direct water splashes, ideal for panel-mount cabinet installations.
10-Point Responsive PCAP Touch
High-accuracy capacitive touch sensor supporting smooth multi-touch gestures, industrial glove operation, and superior scratch resistance.
Fanless Cooling & 24/7 Reliability
Engineered with high-efficiency passive heat dissipation, eliminating noise and moving parts for silent, dust-free continuous 24/7 industrial duty.
Rich Industrial I/O & Wide Power
Equipped with dual Gigabit LAN, multiple RS232/485 serial COM ports, USB 3.0, and 9V–36V wide DC voltage input with overcurrent protection.
Technical Specifications
Advanced Hardware & Technology
Frequently Asked Questions (FAQ)
Q1: How is the panel PC mounted into a control cabinet, and is the cutout waterproof?
The unit comes standard with dedicated panel-mount clamp brackets and a continuous high-density rubber sealing gasket pre-installed behind the aluminum front bezel. When fastened tightly against the cabinet cutout from behind, it achieves an airtight, true IP65 waterproof and dustproof seal, preventing water splashes, industrial coolant, and airborne particulates from penetrating inside the enclosure. Standard VESA 75×75 / 100×100 mm mounting is also supported.
Q2: Does the fanless design support continuous 24/7 operation in dusty factory environments?
Yes. The system utilizes an entirely fanless passive cooling architecture with an extruded heavy-duty aluminum rear chassis acting as a dedicated heatsink. Without mechanical fan vents or rotating blades, internal dust accumulation and fan breakdown risks are completely eliminated. Combined with wide-voltage DC input (9V–36V optional) and industrial-grade solid-state storage, it is rated for MTBF ≥ 50,000 hours of continuous 24/7 operation from -20°C to 60°C.
Q3: What customization options do you provide for bulk OEM/ODM projects?
We offer comprehensive OEM/ODM customization services for industrial system integrators, including:
• Hardware options: Intel J1900 / J6412 / Core i3/i5/i7/i9 processors, RAM up to 32GB, and high-brightness optical bonding up to 1,500 nits.
• I/O adjustments: Additional RS232/422/485 serial ports, isolated GPIO, 4G LTE/5G modules, or CAN bus.
• Branding & enclosure: Silk-screen logo printing, custom bezel finishes (CNC brushed, anodized black, RAL colors), and customized packaging.
• OS: Pre-installed & activated Windows 10/11 Pro, Windows IoT, or custom Linux distributions.
Need a Customized Marine or Industrial Washdown Solution?
Get in touch with Rostar engineering team for sample testing, custom pinouts, and volume pricing.
