Engineered for Secure Operator Authentication & Industrial Control
Unauthorized machine operation and shared access passwords pose critical security risks on modern factory floors. The Rostar Tech Touch Panel PC with Integrated Fingerprint Scanner provides a biometric-secured human-machine interface. Combining an industrial-grade front fingerprint sensor with high-performance Intel processing and an IP65 waterproof aluminum front bezel, it enables fast operator identity verification, role-based access control, and audit trail compliance across CNC machinery, pharma manufacturing, smart lockers, and industrial control cabinets.
Key Engineering Highlights
Biometric Fingerprint Security
Industrial-grade front biometric sensor with fast recognition (<0.5s), supporting Windows Hello, biometric SDKs, and multi-user privilege management.
EETI Touch & Glove Support
10-point PCAP touch with advanced EETI firmware, offering high anti-electromagnetic interference (EMC) and smooth operation with 2mm industrial gloves.
Intel Platform & Windows/Linux
Powered by Intel Celeron / Core i3/i5/i7 processors, providing smooth execution for SCADA, MES clients, and enterprise industrial automation software.
IP65 Bezel & 24/7 Stability
Rugged CNC brushed aluminum housing with IP65-sealed front protection and optimized thermal ventilation, rated for wide-temperature (-20°C to 60°C) continuous duty.
Technical Specifications
| System Parameter | Specification Details |
|---|---|
| Processor (CPU) | Intel Celeron® J1900 / J4125 / J6412 / J6413 (Optional: Intel® Core™ i3 / i5 / i7 / i9) |
| Memory | 8GB DDR3/DDR4 (Optional: 4GB / 16GB) |
| Storage | 128GB SSD (Optional: 256GB / 512GB / 1TB SSD, 2.5" HDD) |
| Operating System (OS) | Windows 10 / 11 Pro, Windows 10 IoT Enterprise, Linux (Ubuntu, Debian, CentOS) |
| Screen Size | 10.1" TFT LCD (7" to 55" available upon request) |
| Resolution | 1280*800 |
| Aspect Ratio | 16:10 |
| Brightness | 300 cd/m² |
| Touch Type | Projected Capacitive (PCAP 10-Point Multi-Touch) / 5-Wire Resistive / Non-Touch |
| Touch Durability | ≥ 50 Million Touches |
| Standard I/O Ports | 2 × USB, 1 × RJ45 |
| Power Input | Standard DC 12V / POE |
| Enclosure Material | Aluminum Alloy+Metal iron case |
| Housing Color | Black |
| Mounting Options | VESA 75×75 / 100×100 mm, Flush Mount |
| Operating Temperature | -20°C to 60°C |
| Certifications | CE, FCC, RoHS |
Advanced Hardware & Technology
Frequently Asked Questions (FAQ)
Q1: Does the integrated fingerprint scanner support Windows, and do you provide an SDK?
Yes. The built-in fingerprint reader comes with pre-configured Windows drivers . For industrial software developers and system integrators, we provide a complete secondary development kit (SDK) with API documentation, enabling role-based operator authentication, access logs, and audit trail integration in your MES, SCADA, or custom control software.
Q2: How does the POE (Power over Ethernet) option work, and does it reduce cabinet wiring?
With the optional POE module, the unit can receive both high-speed network data and operating power simultaneously through a single standard RJ45 Ethernet cable (compatible with standard IEEE 802.3at/bt POE switches). This significantly simplifies installation in smart factory cabinets, kiosks, and cleanrooms by eliminating the need for dedicated AC-to-DC power adapters and separate power cabling. A standard 12V DC input terminal is also provided for conventional power setups.
Q3: How is Flush Mount installation executed, and how does the fanless housing handle heat?
The unit is engineered for seamless Flush Mount and Panel Mount integration into control desks, equipment enclosures, and access panels, fitting flush with zero front protrusion. The aluminum front bezel combined with the heavy-duty metal chassis acts as an efficient passive heat conductor, venting thermal buildup through optimized rear and side heatsink channels. This fanless, vibration-resistant structure ensures silent, maintenance-free 24/7 continuous operation from -20°C to 60°C.
Need a Customized Marine or Industrial Washdown Solution?
Get in touch with Rostar engineering team for sample testing, custom pinouts, and volume pricing.
