All-in-One Smart Terminal with Integrated RFID & QR Code Recognition
Deploying external card readers, barcode scanners, and touchscreens separately in smart factories or kiosk enclosures increases wiring complexity, failure rates, and assembly costs. The Rostar Tech 10.1” Industrial Panel PC integrates a high-frequency RFID/NFC module and an optical 1D/2D QR code scanner directly into a sleek CNC aluminum chassis. Powered by high-performance Rockchip processors (RK3568 / RK3576 / RK3588) with IP65 rating, it delivers an ultra-compact, maintenance-free edge terminal for smart manufacturing, MES tracking, digital access control, and self-service ticketing kiosks.
Key Engineering Highlights
Integrated RFID / NFC Module
Built-in front-bezel 13.56MHz contactless reader supporting rapid operator identity verification, access management, and automated time-attendance logging.
High-Speed 1D/2D Barcode Scanner
Integrated optical CMOS scanning engine with ultra-fast decoding for work orders, paper labels, and smartphone screen codes in MES traceability environments.
Rockchip Quad-Core & Android 13
Powered by high-efficiency RK3568/RK3576/RK3588 processors with Android 11.0/13.0 OS, open SDKs, and hardware neural processing (NPU) for edge computing.
IP65 Front Bezel & Fanless Design
Precision-machined aluminum front bezel with high-density sealing against water splashes, oil mist, and factory dust, combined with passive fanless cooling for 24/7 reliability.
Technical Specifications
Advanced Hardware & Technology
Frequently Asked Questions (FAQ)
Q1: Do you provide an Android SDK/API for the integrated RFID reader and QR code scanner?
Yes. We provide comprehensive Android SDKs, complete sample source code, and developer documentation for both the built-in RFID/NFC reader and the optical 1D/2D QR scanner. The barcode scanner supports both standard HID keyboard emulation mode (instant plug-and-play cursor input) and virtual serial / API broadcast mode, allowing seamless integration into third-party MES, warehouse management, time-attendance, and access control software.
Q2: How is the 10.1" panel PC installed into control cabinets, and does it provide front IP65 protection?
Yes. The unit features an IP65 waterproof and dustproof front bezel equipped with an industrial-grade perimeter rubber sealing gasket. When mounted into a cabinet or machine cutout using the included rear clamp brackets, it forms an airtight seal that protects internal components from water spray, machine oil mist, and airborne factory dust. In addition, standard VESA 75×75 / 100×100 mm mounting holes on the rear chassis support swing arms, desktop stands, and wall brackets.
Q3: Which Rockchip processor should I choose, and what OEM/ODM customization options are available?
• Processor Selection: Rockchip RK3568 is ideal for standard HMI, scanning, and digital signage; RK3576 / RK3588 octa-core processors are recommended for AI-powered edge computing, facial recognition, or high-load industrial vision.
• Customization Services: We support RAM/ROM configurations up to 8GB+128GB, sunlight-readable high-brightness displays up to 1,000 nits, custom I/O breakout modules (RS485, GPIO, 4G LTE), front bezel silk-screen logo printing, and pre-installed customer APKs/launcher firmware.
Need a Customized Marine or Industrial Washdown Solution?
Get in touch with Rostar engineering team for sample testing, custom pinouts, and volume pricing.
